TECHNICAL DATA
Specifications
|
Application:
|
Widely Used On Various Marine Platforms, Chemical Tankers, LNG Ships And Dangerous Goods Vessels
|
Material:
|
Steel
|
|
Protection Level:
|
IP66
|
Color:
|
Silver
|
|
Rated Voltage:
|
≤690V AC
|
Corrosion-proof:
|
WF2
|
Product Introduction
Specification
| Compliance | IEC60079, EN60079, GB3836, GB12476,CCS standard |
| Ex-Mark | Ex e IIC T6 Gb/Ex tD A21 IP66 T80℃
Ex e IIC T4 Gb/Ex tD A21 IP66 T130℃ Ex e IIC T5 Gb/Ex tD A21 IP66 T95℃ Ex e IIC T4 Gb/Ex tD A21 IP66 T130℃ Ex e IIC T3 Gb/Ex tD A21 IP66 T195℃ |
| Rated voltage | ≤690V AC |
| Rated current | ≤630A
80A＜I≤630A ≤10A 16A＜I≤400A 500A＜I≤630A |
| Degree of protection | IP66 |
| Corrosion-proof | WF2 |
| Terminal | Special terminal |
| Cable gland | The products can be supplied with cable gland,if needed, please select other cable glands in accordance with our company’s relevant product selection manual. |
