TECHNICAL DATA
Specifications
|
Explosion Protection:
|
CENELEC,IEC,NEC
|
Can Be Used In:
|
Zone1,2,21,22,Class I,Zone 1,2.Class I,Division 2,Groups A,B,C,D
|
|
Degree Of Protection:
|
IP66
|
Conformity To Standards:
|
EN;IEC
|
|
Material:
|
GRP (glass Fibre-reinforced Polyester Resin)
|
Color:
|
Black
|
Product Introduction
Specification
| Global (IECEx) | IECEx CQM 14.0033X |
| Gas and Dust | Ex db eb mb llCT5 Gb(Ta:-20℃/-40℃~+40℃) Ex db eb mb llCT4 Gb(Ta:-20℃/-40℃~+55℃) Extb lllCT80℃ Db(Ta:-20℃/40℃~+55℃) When the product is equipped with an explosion-proof heater, the marking is: Ex db eb mb llC T4 Gb(Ta:-20℃/-40℃~+45℃) Ex tb lllC T80℃ Db(Ta:-20℃/-40℃~+45℃) Note: protection type “mb” depends on the use of Ex component certified voltmeter or fuse module. |
| Europe (ATEX) | EPT 15 ATEX 2265 |
| Gas and Dust |  II 2 G Ex db eb mb llC T5 Gb(Ta:-20℃/-40℃-+40℃)
Note: protection type “mb” depends on the use of Ex component certifiedvoltmeter or fuse module. |
| Certificates | IECEx; ATEX;CU-TR |
| Conformity to standards | EN;IEC |
| Degree of protection | IP66 |
| Ambient temperature | -40℃(-20℃)~+55℃(+45℃+40℃) |
Data
| Material | GRP (glass fibre-reinforced polyester resin) |
| Color | Black |
| Dimensions | As per design |
| Rated voltage | Max. 690V AC 50/60Hz |
| Rated current | Max.250A |
| Cable entries | Standard M□ x 1.5 plug |
| Cable gland (optional) | DQM-I(Ex e) |
| Mounting | Surface type (Standard) |
