DQM-II Series Waterproof Ex...
- Place of Origin: China
- Brand Name: Warom
- Certification: IECEx; ATEX; CU-TR
- Model Number: DQM-II
- Packaging Details: carton packing/wooden box package
- Payment Terms: T/T
TECHNICAL DATA
Specifications
| Explosion Protection: | CENELEC,IEC,NEC | Can Be Used In: | Zone1,2,21,22,Class I,Zone 1,2.Class I,Division 1,Groups A,B,C,D |
| Type: | MG,PG | Materials: | BRASS,Stainless Steel |
| Application: | Indoor/Outdoor | Operating Temperature: | -40°C To 100°C |
| Protecetion Class: | IP67 |
Product Introduction
Specification
| Global (IECEx) | IECEx LCI 08.0011X |
| Gas and Dust | Ex db IIC Gb
Ex eb IIC Gb Ex tb IIIC Db IP66 |
| Europe (ATEX) | LCIE 06 ATEX 6100X |
| Gas and Dust |
II 2 G Ex d IIC Gb;
II 2 G Ex e IIC Gb;
II 2 D Ex tb IIIC Db IP66 |
| Certificates | IECEx; ATEX; CU-TR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66/IP67 |
| Ambient temperature | -60℃~+100℃ |
Data
| Material | Stainless steel or nickel plated brass |
| Ambient temperature | -60℃~+100℃ |
| Type | M; G; NPT |
| Connection thread | Metric thread is standard type; G thread or NPT thread is optional |
