HRD96 Series Explosion Proof...
- Place of Origin: China
- Brand Name: Warom
- Certification: IECEx; ATEX;
- Model Number: HRD96
- Packaging Details: carton packing/wooden box package
- Payment Terms: T/T
TECHNICAL DATA
Specifications
| Applicable Lamp And Power (max.120W): | LED : 30W, 60W, 120W | Explosion Protection: | CENELEC,IEC,NEC |
| Can Be Used In: | Zone 1,2,21,22 Class I, Zone 1,2 Division 1, Groups A, B, C, D | Three Enclosure Type: | 30, 60, 120 |
| Dimensions: | 316x316x118mm | Rated Luminous Flux: | 3150~12300lm |
Product Introduction
Specification
| Global (IECEx) | IECEx (applied for) |
| Gas and dust | Ex db IIC T6 Gb
Ex tb IIIC T80℃ Db |
| Europe (ATEX) | ATEX (applied for) |
| Gas and dust |
II 2 G Ex db IIC T6 Gb |
|
II 2 D Ex tb IIIC T80℃ Db |
|
| Certificates | IECEx; ATEX |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -40℃~+55℃ |
Data
| Material | Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021)
Toughened glass, stands 4J impact |
| Weight | 2~5.5kg |
| Dimensions | 316x316x118mm |
| Lamp specification | LED module, Multiple LED |
| Lamp power (W) | 30W, 60W, 120W |
| Rated voltage | 220~240V AC 50/60Hz |
| Rated luminous flux | 3150~12300lm |
| Terminal | 3 x 1.5~4mm2(L+N+PE) |
| Cable entries | M25 x 1.5 |
| Available cable outer diameter | Φ10~Φ14 (mm) |
