HRT96 Series Explosion Proof...
- Product Details
- Place of Origin: China
- Brand Name: Warom
- Certification: IECEx; ATEX;
- Model Number: HRT96
- Payment & Shipping Terms
- Packaging Details: carton packing/wooden box package
- Payment Terms: T/T
TECHNICAL DATA
Specifications
| Explosion Protection: | CENELEC,IEC,NEC | Can Be Used In: | Zone 1 And Zone 2 Zone 21 And Zone 22 Class L, Zone 1 And Zone 2 Class L, Division 1, Groups A, B, C, D |
| Pplicable Lamp And Power (max.240W): | LED: 80W,160W,240W |
Product Introduction
Specification
| Global(IECEx) | IECEx(applied for) |
| Gas and dust | Ex db IIC T6 Gb
Ex tb IIIC T80℃ Db IP66 |
| Europe(ATEX) | ATEX (applied for) |
| Gas and dust |
II 2 G Ex db IIC T6 Gb II 2 D Ex tb lllC T80℃ Db IP66 |
| Certificates | IECEx ; ATEX |
| Conformity to standards | EN 60079-0,EN 60079-1,EN60079-28,EN 60079-31
IEC60079-01EC 60079-1,IEC60079-28IEC 60079-31 |
Data
| Material | Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021)
Toughened glass, stands 4J impact Stainless steel |
| Lamp specification | LED module, Multiple LED |
| Lamp power (W) | 80W,160W,240W |
| Colour temperature (CCT) | 5700K |
| Rated voltage | 220~240VAC50/60Hz |
| Degree of protection | IP66 |
| Ambient temperature | -40°C~+55°C |
| Mounting | Fixed type, street lamp type |
| Cable entries | M25 x 1.5 plugs |
| Cable gland | DQM-Il(Ex d)or DQM-Ill(Ex d)is recommended |
