HRX Series Explosion-proof LED...



Product Parameters

Product Type: HRX

Standards: CENELEC, IEC, NEC

Zones:

• Zone 1 amd Zone 2
• Zone 21 and Zone 22
• Class I, Zone 2 and Zone 2
• Class I, Division 1, Groups A, B, C, D

• Explosion protection:

• IECEx (Gas and dust): Ex db eb mb IIC T6 Gb; Ex tb IIIC T80°C Db
• ATEX (Gas and dust): II 3 G Ex db IIC T6 Gb; II 2 D Ex tb IIIC T80°C Db

Technical Details:

• Material:
  • Enclosure: Copper-free Aluminium Alloy, powder coated surface.
  • Glass cover: Polycarbonate, stands 4J impact.
  • Exposed fastener: Stainless steel.
• LED driver: Wide voltage input, CC-CV output, power factor ≥0.95, with function of distributed current, constant current,surge-proof and anti-electromagnetic interference, and protection against overcurrent, open circuit, and short circuit.
• Lamp specification: LED module, Multiple LED
• Lamp power: 10W, 20W, 30W
• Rated luminous flux: 1300~3300lm
• Color rendering index: ≥80
• Colour temperature: 5000K Note: nature white is available in general. Warm white is optional, please specify when ordering.
• Rated voltage: 100~277V AC 50/60Hz, 24V DC, 36V DC
• Degree of protection: IP66
• Ambient temperature: -40℃~+60℃
• Terminal: 3 x 1.5~4mm² (L+N+PE)
• Cable entries: 2 x M25 x 1.5 plugs
• Cable gland: DQM-I (Ex eb) is recommended
• HS code: 940561
• Country of origin: China

Applicable Industries

Explosion-Proof LED Lightings is specifically engineered for a wide range of industries and hazardous environments, including petrochemical, natural gas, coal, metallurgy, military, nuclear power, aerospace, firefighting, pharmaceuticals, textiles, grain & oil, municipal services, public security, shipping, ports, railways and so on.

It incorporates core advantages such as a high-strength explosion-proof structure, excellent sealing performance, high efficiency and energy savings, long service life, corrosion resistance, impact resistance, easy maintenance, and flexible installation. Capable of stable operation under harsh environmental conditions including high temperatures, dusty atmospheres, and corrosive gases, it provides continuous, reliable, safe, and bright lighting assurance for personnel in Hazardous Area.

Credibility

Warom Explosion-Proof Light Fittings meet the most stringent international standards, carrying full ATEX, IECEx, and EAC certifications to ensure compliance across the global markets. Built to endure extreme conditions, our lighting luminaires boast IP65/IP66/IP67 ratings, being completely waterproof, dustproof and corrosion-resistant. We partner with clients through comprehensive technical support, robust warranty coverage, and global logistics. Wherever you operate, Warom ensures seamless project execution for safe and reliable illumination solutions in hazardous areas.

Warom Explosion-Proof Lighting: Engineered for Global Compliance and Reliability.

FAQ

Q1: Are the explosion-proof LED lightings suitable for outdoor environments?
A: Yes, the product features an IP66 protection rating, enabling it to withstand outdoor rain, snow, and dusty conditions.
Q2: Do you support customization for different voltages?
A: Yes, we support customization and can provide a range of voltages from 100V to 277V among other custom voltage specifications.
Q3: How many types of light distribution options are available?
A: This lamp is available in both floodlight and spotlight options.
