TECHNICAL DATA
Specifications
| Explosion Protection: | CENELEC,IEC | Can Be Used In: | Zone 1, 2, 21, 22 |
| Product Type: | Cabinet | Size: | Customizable |
| Material: | Powder Coated Carbon Steel Or Stainless Steel | Certifications: | IECEx; ATEX |
| Type: | Explosion-proof |
Product Introduction
Specification
| Global (IECEx) | IECEx CQM19.0019X |
| Gas and dust | Ex db eb pxb IIC T4 Gb
Ex pxb tb IIIC T130℃ Db IP66 |
| Europe (ATEX) | ATEX(applied for) |
| Gas and dust |
II 2 G Ex db eb pxb IIC T4 Gb
II 2 D Ex pxb tb IIC T130℃ Db IP66 |
| Certificates | IECEx; ATEX;CUTR;INMETRO |
| Conformity to standards | EN;IEC |
Data
| Positive pressure value | 200Pa~800Pa(0.002bar~0.008bar) |
| Air sourre | 0.2MPa~0.8MPa (2bar~8bar) |
| Rated voltage | Max. 1000V AC 50/60Hz
Max. 1500V DC |
| Rated current | Max. 630A |
| Enclosure material | Powder coated carbon steel or stainless steel |
| Degree of protection | IP66 |
| Ambient temperature | -40℃~+55℃ |
