BPC-X Series Explosion-proof Monitor

Explosion Protection Type

• Standards: CENELEC, IEC, NEC
• Hazardous Area Zones:
  • Zone 1 and Zone 2
  • Zone 21 and Zone 22

Product Parameters

• Explosion Protection Ratings:
  • IECEx (Gas): Ex db IIB T6 Gb
  • IECEx (Dust): Ex tb IIIC T80°C Db
  • ATEX (Gas): II 2 G Ex db IIB T6 Gb
  • ATEX (Dust): II 2 D Ex tb IIIC T80°C Db
• Product Type: BPC-X
• Degree of Protection: IP66
• Brightness: 350cd/m2 (>600cd/m2 optional)
• Operating Mode: Fingertip or touch-pen operation (explosion-proof keyboard and mouse optional)
• CPU: Intel Core i5 / Intel Core i7
• Memory: 8 GB (16GB, 32GB optional)
• Storage: 128G SSD (256G, 512G, 1T SSD optional)
• Ethernet: 2*10/100/1000 Mbps Ethernet/R45
• Serial Port: 4*RS485/RS422 /RS232
• USB: USB 3.0, with extension capability for 2 USB 2.0
• Operating System: Win 7, Win 10, Win 11, Kirin (Domestic version)
• Operating Temperature: -40°C to +60°C
• Operating Voltage: 220VAC, 110VAC / 24VDC
• Installation Method: Wall-mounted, flush-mounted on front panel, optional column/cantilever/wall-mounted console

Classification & Origin

• HS Code: None
• Country of Origin: China

Industry & Application

• Core Function: A rugged computing solution (explosion-proof monitor) specifically engineered for volatile environments to prevent ignition through intrinsic safety or flameproof enclosures.
• Applicable Industries: Oil and gas, petrochemical, mining, military, offshore oil platforms, and cruise ships.
• Certifications: Engineered to the highest safety benchmarks and pursuing/holding key certifications including ATEX, IECEx, and EAC.

FAQ (Frequently Asked Questions)

• Q1: What is an explosion-proof monitor? How is it different from a regular tablet?
• A1: It is specifically engineered for flammable environments using technologies like intrinsic safety or flameproof enclosures to prevent ignition. Regular rugged tablets only offer basic protection and are not certified for explosive atmospheres.
• Q2: In which hazardous areas can it be safely used?
• A2: These units are certified for safe operation in Zone 1 and Zone 2 hazardous areas. Usage must strictly match the certified zone.
• Q3: Are there special requirements for battery life and charging?
• A3: Safety charging is critical: You must use the original, explosion-proof certified charger. Charging in a hazardous area is strictly forbidden.
• Q4: What should I do if the screen or housing is damaged?
• A4: Immediately cease use in any hazardous area as damage can compromise the explosion-proof seals. Contact official after-sales service for professional repair; do not disassemble the device yourself.
• Q5: What are the absolute prohibitions for daily use?
• A5: Never charge or disassemble the device in a hazardous area; never use non-original batteries or chargers; and never continue using the device in a hazardous area if the housing is cracked or damaged.
