HK Series Control Switches

◆ This explosion-proof control stations are made of Copper-free Aluminium Alloy, can ensure safety by containing internal explosions and isolating the external hazardous atmosphere.
◆ The explosion proof enclosures treated with anti-static coating and all fasteners are anti-loosening.
◆The layout of buttons, switches, and other componentson of the explosion-proof control panel is rational and straightforward,ensuring ease of use and quick mastery.
◆The control methods of ex control station can be selected based on actual needs, such as manual control, automatic control, or remote control, catering to varying application scenarios.

TECHNICAL DATA

Standards: CENELEC, IEC, NEC
Zones: * Zone 1 and Zone 2
- Zone 21 and Zone 22
- Class I, Zone 1 and Zone 2
- Class I, Division 1, Groups A, B, C, D
Explosion Protection Ratings:
- IECEx (Gas and dust): Ex db IIC Gb; Ex tb IIIC Db IP66
- ATEX (Gas and dust): II 2 G Ex db IIC Gb; II 2 D Ex tb IIIC Db IP66

Product Type: HD
Enclosure Color: Window grey (RAL7040)
Rated Voltage: * 440V AC, 50/60Hz
- 220~415V AC, 50/60Hz
- 220V DC
- 48~120V AC/DC
- 12~36V AC/DC
Degree of Protection: IP66
Ambient Temperature: -60°C ~ +70°C

Target Industries: Heavy industries including oil and gas, petrochemical, coal, metallurgy, military, nuclear power, aerospace, and more.
Functional Utility: This explosion-proof control panel features a multi-position, multi-contact design for complex command sequences like forward-reverse-speed change-stop.
Safety Performance: Certified flameproof design ensures it will not become an ignition source in harsh industrial environments.

Global Certifications: Engineered for safety and certified to ATEX, IECEx, EAC, and other stringent requirements.
Service Commitment: Committed to providing professional lighting solutions, customized configurations, and technical service support.

Q1: What does “Explosion-proof” mean for an explosion-proof control station?
- A: It signifies the device’s ability to prevent the ignition of a surrounding explosive atmosphere by containing internal sparks or limiting energy levels.
Q2: In which industries are explosion-proof operator stations primarily used?
- A: They are used in environments with flammable gases or dusts, such as oil & gas platforms, refineries, chemical plants, and food processing facilities.
Q3: Can we open the operator station ourselves for maintenance?
- A: No. Only specially trained and authorized personnel may open Ex control stations in confirmed safe areas to maintain explosion-proof integrity.
