Product Details
Payment & Shipping Terms
| Global (IECEx) | IECEx CQM 22.0024 X |
| Gas and dust |
Ex nR IIC T□1) Gc Ex tb IIIC T□1) Db |
| Europe (ATEX) | TÜV CY 23 ATEX 0206765X |
| Gas and dust |
|
| Certificates | IECEx; ATEX; |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -40℃~+55℃ |
| Material |
Enclosure:Aluminium Alloy, powder coated surface |
| Lamp holder | E40 |
| Lamp specification | High pressure sodium lamp (HSE) |
| Lamp power (W) | 150W,250W, 400W |
| Rated voltage | 220-240V AC 50Hz,220~240V AC 60Hz,415V AC 50Hz |
| Earthing protection | M5(Internal & External earth bolts) |
| Terminal | 3 x 1.5~4mm2 (L+N+PE) |
| Cable entries |
1xM20x1.5 cable gland (DQM-| Ex e, metal unarmored) |
HRD95 Series Explosion-proof LED Lightings
(Download here:BAM52 Series Explosion-proof Street Lamps.pdf)
Global (IECEx): IECEx CNEX 18.0024 X
(Download here:ECEx CQM 22.0024X Issue No.0(T4 T3).pdf)
