Product Details
Place of Origin: China
Brand Name: Warom
Certification: IECEx; ATEX; CU-TR
Model Number: HRY97
Payment & Shipping Terms
Packaging Details: carton packing/wooden box package
Payment Terms: T/T
Explosion Protection: |
CENELEC,IEC,NEC |
Can Be Used In: |
Zone 1,Zone 2,Zone 21,Zone 22 |
Three Enclosure Types: |
Type I, Type II And Type III Available Lamp And Power Type I: 20W Type II: 40W Type III: 60W |
Enclosure In: |
Copper-free Aluminium Alloy, Powder Coated Surface, Yellow (RAL1021) |
Weight: |
5.50~6.50kg |
Lamp Power (W): |
20W, 40W, 60W |
Explosion Protection: |
CENELEC,IEC,NEC |
Can Be Used In: |
Zone 1,Zone 2,Zone 21,Zone 22 |
Three Enclosure Types: |
Type I, Type II And Type III Available Lamp And Power Type I: 20W Type II: 40W Type III: 60W |
Enclosure In: |
Copper-free Aluminium Alloy, Powder Coated Surface, Yellow (RAL1021) |
Weight: |
5.50~6.50kg |
Lamp Power (W): |
20W, 40W, 60W |
Product Introduction
Specification
Global (IECEx) |
IECEx CQM 24.0001X |
Gas and dust |
II 2 G Ex db eb mb IIC T6 Gb II 2 D Ex tb IIIC T80℃ Db |
Certificates | IECEx; ATEX; CU-TR |
Conformity to standards | EN.IEC |
Degree of protection | IP66 |
Ambient temperature | -40℃~+60℃ |
Data
Material | Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021) |
Weight | 5.50~6.50kg |
Dimentions | |
Lamp specification | LED module (supplied with the light fittings) |
Lamp power (W) | 20W, 40W, 60W |
LED Colour temperature (CCT) |
5000K Note: nature white is available in general. Warm white or cool white is optional, please specify when ordering. |
Rated voltage | 100-277V AC 50/60Hz 130~250V DC |
Earthing protection | M4 (internal & external earth bolts) |
Terminal | 3 x 1.5~4mm2 (L+N+PE) |
Cable entries | 1 x M25 x 1.5 plugs+1 x M25 x 1.5 |
cable gland | DQM-I, Stainless steel |
Download
HRY97 Series Explosion-proof High Efficiency Energy-saving LED Lamps
(Download here:HRY97 Series Explosion-proof High Efficiency Energy-saving LED Lamps.pdf)
Global (IECEx): IECEx CQM 24.0001X
(Download here:IECEx CQM 24.0001X Issue No.0.pdf)
