TECHNICAL DATA
Specifications
Explosion Protection: | CENELEC,IEC,NEC | Can Be Used In: | Zone1,2,21,22,Class I,Zone 1,2.Class I,Division 1,Groups B,C,D |
Product Introduction
Specification
| Global (IECEx) | IECEx CML 18.0157X |
| Gas and Dust | Ex db IIB+H2 T□1) Gb Ex db [ib] IIB+H2 T□1) Gb Ex tb IIIC T□1) Db IP66 |
| Europe (ATEX) | CML 18 ATEX 1338X |
| Gas and Dust |   II 2 G Ex db IIB+H2 T□1) Gb
|
| Certificates | IECEx; ATEX;CUTR |
| Conformity to standards | EN; IEC |
| Degree of protection | IP66 |
| Ambient temperature | -60℃ ~ +60℃(+40℃) |
Data
| Material | Copper-free Aluminium Alloy, powder coated surface,Window grey (RAL7040) |
| Exposed fastener | Stainless steel |
| Dimensions | As per design |
| Rated voltage | Max. 1000V AC 50/60Hz； Max. 1500V DC |
| Rated current | Max. 1200A |
| Internal&external earthing | M6/M8;M8/M8 |
| Cable entries | As per design |
| Cable gland (optional) | DQM-l (Ex d) or DQM-ll (Ex d)is recommended. Please see P7/22~31 |
| Entry direction | Bottom |
| Mounting | Surface type (standard) Pedestal type (optional) |
