BBJ86 Caution Spotlight Fittings
- ◆ This Caution Spotlight Fittings Ex e enclosure with explosion-proof components inside.
- ◆ Expolosion proof Caution Spotlight fittings Interlock function between enclosure and diffuser, switches off on opening.
- ◆ Caution Spotlight Fittings is built-in electronic ballast, power factor ≥0.95.
- ◆ Emergency lighting fixtures unit is equipped with protections against overcharge and overdischarge.
- ◆ End of explosion proof lamp life (EOL) rectification effect protection.
TECHNICAL DATA
Explosion Protection Type
- Standards: CENELEC, IEC, NEC
- Zones:
- Zone 1 and Zone 2
- Zone 21 and Zone 22
- Class I, Zone 1 and Zone 2
- Class I, Division 2, Groups A, B, C, D
Product Parameters
- Explosion protection:
- IECEx (Gas and dust): Ex db ib IIC T6 Gb; Ex tb IIIC T80°C Db
- ATEX (Gas and dust): II 2 G Ex d ib IIC T6 Gb; II 2 D Ex t IIIC T80°C Db IP66
- Product Type: BBJ81
- Rated voltage:
- IECEx: 220~240V AC 50/60Hz; 100~120V AC 50/60Hz; 24V DC/AC
- ATEX: 220~240V AC 50/60Hz; 24V DC/AC
- Material:
- Enclosure: Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021)
- Transparent cover: Toughened glass, stands 4J impact
- Exposed fastener: Stainless steel
- Lamp specification: LED
- Lamp power (W): 5W
- Lamp colour: Red, blue, yellow, green
- Sound intensity: 85~105dB (R=1m)
- Flash frequency: 70 (times/min)
- Earthing protection: M5 (internal & external earth bolts)
- Degree of protection: IP66
- Ambient temperature: -40°C~+55°C
- Terminal: 3 x 1.5~2.5mm² (L+N+PE)
- Cable entries: 3 x M25 x 1.5 plugs
- HS code: 940549
- Country of origin: China
Applicable Industries
Explosion-Proof Caution Spotlight is specifically engineered for a wide range of industries and hazardous environments, including petrochemical, natural gas, coal, metallurgy, military, nuclear power, aerospace, firefighting, pharmaceuticals, textiles, grain & oil, municipal services, public security, shipping, ports, railways and so on.
It incorporates core advantages such as a high-strength explosion-proof structure, excellent sealing performance, high efficiency and energy savings, long service life, corrosion resistance, impact resistance, easy maintenance, and flexible installation. Capable of stable operation under harsh environmental conditions including high temperatures, dusty atmospheres, and corrosive gases, it provides continuous, reliable, safe, and bright lighting assurance for personnel in Hazardous Area.
Credibility
Warom Explosion-Proof Light Fittings meet the most stringent international standards, carrying full ATEX, IECEx, and EAC certifications to ensure compliance across the global markets. Built to endure extreme conditions, our lighting luminaires boast IP65/IP66/IP67 ratings, being completely waterproof, dustproof and corrosion-resistant. We partner with clients through comprehensive technical support, robust warranty coverage, and global logistics. Wherever you operate, Warom ensures seamless project execution for safe and reliable illumination solutions in hazardous areas.
Warom Explosion-Proof Lighting: Engineered for Global Compliance and Reliability.
FAQ
- Q1: Are the explosion-proof fluorescent lights suitable for outdoor environments?
- A: Yes, the product features an IP66 protection rating, enabling it to withstand outdoor rain, snow, and dusty conditions.
- Q2: Do you support customization for different voltages?
- A: Yes, we support customization and can provide a range of voltages from 110V to 250V among other custom voltage specifications.
- Q3: What installation options are available?
- A: We offer various flexible installation methods, including pendant mounting, wall mounting, ceiling mounting, and pendant chain installation.
