BAK51 Caution Spotlight Fittings
- ◆ This Caution Spotlight Fittings Ex e enclosure with explosion-proof components inside.
- ◆ Lighting angle can be adjusted.
- ◆ Available for 35W or 50W halogen tungsten lamp, with high light efficiency and long service life.
- ◆ Toughened glass cover resistant to temperature changes.
TECHNICAL DATA
Product Parameters
- Product Type: BAK51
- Standards: CENELEC, IEC, NEC.
- Zones:
- Zone 1 and Zone 2.
- Zone 21 and Zone 22.
- Explosion protection:
- IECEx (Gas and dust): Ex db IIB T3 Gb; Ex tb IIIC T190°C Db.
- ATEX (Gas and dust): II 2 G Ex db IIB T3 Gb; II 2 D Ex tb IIIC T190°C Db.
- Material:
- Enclosure: Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021).
- Glass cover: Toughened glass, impact resistance and high light transmission.
- Exposed fastener: Stainless steel.
- Rated voltage: 220~240V AC 50Hz; 12V DC; 24V AC/DC
- Available lamp: Halogen tungsten lamp.
- Lamp holder: GY6.35.
- Lamp power (W): 35W, 50W.
- Adaptable voltage: DC 12V
- Earthing protection: M5 (internal & external earth bolts).
- Degree of protection: IP66.
- Charging time: 16h.
- Ambient temperature: -60°C~+60°C.
- Terminal: 3 x 1.5~2.5mm² (L+N+PE).
- Cable entries: 1 x G3/4″.
- Available cable outer diameter: Φ10~Φ14 (mm).
- HS code: 940549.
- Country of origin: China.
Applicable Industries
Explosion-Proof Caution Spotlight is specifically engineered for a wide range of industries and hazardous environments, including petrochemical, natural gas, coal, metallurgy, military, nuclear power, aerospace, firefighting, pharmaceuticals, textiles, grain & oil, municipal services, public security, shipping, ports, railways and so on.
It incorporates core advantages such as a high-strength explosion-proof structure, excellent sealing performance, high efficiency and energy savings, long service life, corrosion resistance, impact resistance, easy maintenance, and flexible installation. Capable of stable operation under harsh environmental conditions including high temperatures, dusty atmospheres, and corrosive gases, it provides continuous, reliable, safe, and bright lighting assurance for personnel in Hazardous Area.
Credibility
Warom Explosion-Proof Light Fittings meet the most stringent international standards, carrying full ATEX, IECEx, and EAC certifications to ensure compliance across the global markets. Built to endure extreme conditions, our lighting luminaires boast IP65/IP66/IP67 ratings, being completely waterproof, dustproof and corrosion-resistant. We partner with clients through comprehensive technical support, robust warranty coverage, and global logistics. Wherever you operate, Warom ensures seamless project execution for safe and reliable illumination solutions in hazardous areas.
Warom Explosion-Proof Lighting: Engineered for Global Compliance and Reliability.
FAQ
Q1: How to select the appropriate Explosion-proof LED Tank Inspection Vessel Light for your application environment?
A1: During selection, it is essential to ensure that the explosion-proof rating of the equipment strictly matches the site conditions. Key considerations include: hazardous area classification, gas group, and ingress protection (IP) rating.
Q2: What are the advantages of Explosion-Proof Caution Spotlight compared to traditional light sources?
A2: Energy efficiency and high luminous efficacy, extended service life, and environmental friendliness (no mercury, no UV radiation).
Q3: What are the voltage requirements for the power supply?
A3: Explosion-proof sight glass lights are available in various voltage options, such as 12V, 24V, 36V, 48V, 277V and so on.
