BAK85 Caution Spotlight Fittings



Explosion Protection Type

• Product Type: BAK85
• Standards: CENELEC, IEC, NEC.
• Zones:
  • Zone 1 and Zone 2.
  • Zone 21 and Zone 22.

Product Parameters

• Explosion protection:
  • IECEx (Gas and dust): Ex db op is llC T6 Gb; Ex tb op is llIC T80’℃ Db
  • ATEX (Gas and dust): II 2 G Ex db op is llC T6 Gb; II 2 D Ex tb op is llIC T80’℃ Db
• Material:
  • Enclosure: Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021).
  • Glass cover: Toughened glass, impact resistance and high light transmission.
  • Exposed fastener: Stainless steel.
• LED driver: Wide voltage input, CC-CV (constant current – constant voltage) output, power factor ≥0.95, with protection against circuit and anti-electromagnetic interference, etc.
• Rated voltage: 100~277V AC 50/60Hz,100~250V DC,12~36V 50/60Hz 12~48V DC
• Lamp specification: International brand of LED module
• Lamp power (W): 9W
• Colour Temperature (CCT): 5700K Note: cool white is available in general. Warm white or nature white is optional,.please specify when ordering.
• Earthing protection: M5 (internal & external earth bolts)
• Degree of protection: IP66/IP67
• Ambient temperature: -40℃~+55℃
• Terminal: 3 x 1.5~2.5mm² (L+N+PE).
• Cable entries: M20 x1.5
• Cable gland: Supplied with seal gasket and gland nut
• Available cable outer diameter: Φ16~Φ20 (mm).
• HS code: 940549.
• Country of origin: China.

Applicable Industries

Explosion-Proof Caution Spotlight is specifically engineered for a wide range of industries and hazardous environments, including petrochemical, natural gas, coal, metallurgy, military, nuclear power, aerospace, firefighting, pharmaceuticals, textiles, grain & oil, municipal services, public security, shipping, ports, railways and so on.

It incorporates core advantages such as a high-strength explosion-proof structure, excellent sealing performance, high efficiency and energy savings, long service life, corrosion resistance, impact resistance, easy maintenance, and flexible installation. Capable of stable operation under harsh environmental conditions including high temperatures, dusty atmospheres, and corrosive gases, it provides continuous, reliable, safe, and bright lighting assurance for personnel in Hazardous Area.

Credibility

Warom Explosion-Proof Light Fittings meet the most stringent international standards, carrying full ATEX, IECEx, and EAC certifications to ensure compliance across the global markets. Built to endure extreme conditions, our lighting luminaires boast IP65/IP66/IP67 ratings, being completely waterproof, dustproof and corrosion-resistant. We partner with clients through comprehensive technical support, robust warranty coverage, and global logistics. Wherever you operate, Warom ensures seamless project execution for safe and reliable illumination solutions in hazardous areas.

Warom Explosion-Proof Lighting: Engineered for Global Compliance and Reliability.

FAQ

Q1: How to select the appropriate Explosion-proof LED Tank Inspection Vessel Light for your application environment?
A1: During selection, it is essential to ensure that the explosion-proof rating of the equipment strictly matches the site conditions. Key considerations include: hazardous area classification, gas group, and ingress protection (IP) rating.
Q2: What are the advantages of Explosion-Proof Caution Spotlight compared to traditional light sources?
A2: Energy efficiency and high luminous efficacy, extended service life, and environmental friendliness (no mercury, no UV radiation).
Q3: What are the voltage requirements for the power supply?
A3: Explosion-proof sight glass lights are available in various voltage options, such as 12V, 24V, 36V, 48V, 277V and so on.
