BBJ81 Caution Spotlight Fittings



Product Parameters

• Product Type: BBJ81
• Standards: CENELEC, IEC, NEC
• Zones:
  • Zone 1 and Zone 2
  • Zone 21 and Zone 22
  • Class I, Zone 1 and Zone 2
  • Class I, Division 2, Groups A, B, C, D
• Explosion protection:
  • IECEx (Gas and dust): Ex db ib IIC T6 Gb; Ex tb IIIC T80°C Db
  • ATEX (Gas and dust): II 2 G Ex d ib IIC T6 Gb; II 2 D Ex t IIIC T80°C Db
• Material:
  • Enclosure: Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021)
  • Transparent cover: Toughened glass, stands 4J impact
  • Exposed fastener: Stainless steel
• Rated voltage:
  • IECEx: 220~240V AC 50/60Hz; 100~120V AC 50/60Hz; 24V DC/AC
  • ATEX: 220~240V AC 50/60Hz; 24V DC/AC
• Lamp specification: LED
• Lamp power (W): 5W
• Lamp colour: Red, blue, yellow, green
• Sound intensity: 85~105dB (R=1m)
• Flash frequency: 70 (times/min)
• Earthing protection: M5 (internal & external earth bolts)
• Degree of protection: IP66
• Ambient temperature: -40°C~+55°C
• Terminal: 3 x 1.5~2.5mm² (L+N+PE)
• Cable entries: 3 x M25 x 1.5 plugs
• Cable gland (optional): DQM-II (Ex d) or DQM-III (Ex d) is recommended
• HS code: 940549
• Country of origin: China

Applicable Industries

Explosion-Proof Caution Spotlight is specifically engineered for a wide range of industries and hazardous environments, including petrochemical, natural gas, coal, metallurgy, military, nuclear power, aerospace, firefighting, pharmaceuticals, textiles, grain & oil, municipal services, public security, shipping, ports, railways and so on.

It incorporates core advantages such as a high-strength explosion-proof structure, excellent sealing performance, high efficiency and energy savings, long service life, corrosion resistance, impact resistance, easy maintenance, and flexible installation. Capable of stable operation under harsh environmental conditions including high temperatures, dusty atmospheres, and corrosive gases, it provides continuous, reliable, safe, and bright lighting assurance for personnel in Hazardous Area.

Credibility

Warom Explosion-Proof Light Fittings meet the most stringent international standards, carrying full ATEX, IECEx, and EAC certifications to ensure compliance across the global markets. Built to endure extreme conditions, our lighting luminaires boast IP65/IP66/IP67 ratings, being completely waterproof, dustproof and corrosion-resistant. We partner with clients through comprehensive technical support, robust warranty coverage, and global logistics. Wherever you operate, Warom ensures seamless project execution for safe and reliable illumination solutions in hazardous areas.

Warom Explosion-Proof Lighting: Engineered for Global Compliance and Reliability.

FAQ

Q1: What is an Caution Spotlight Fittings? What are its main applications?
A1: Caution Spotlight Fittingst is an aviation warning device specifically designed for hazardous explosive environments. It is used to mark the contours of tall structures such as high-rise buildings, chimneys, and towers to prevent aircraft collisions. It is suitable for: explosive gas atmospheres, combustible dust atmospheres, and special locations such as petroleum refining, chemical and pharmaceutical facilities, military installations, drilling platforms, and oil storage facilities.
Q2: What equipment can the explosion-proof audible and visual alarm be used with?
A2: Fire alarm control panel, manual call point, gas detector, and PLC/DCS system.
Q3: Is the sound of the Explosion-Proof Sound & Light Alarm selectable?
A3: Yes. Depending on the application requirements, a variety of sound patterns are available, such as fire engine, police car, ambulance, or other customized tones.
