BXK-B Series Explosion-proof Insulated...



Product Parameters

• Product Type: BXK-B
• Standards: CENELEC, IEC, NEC.
• Zones: Zone 1 and Zone 2; Zone 21 and Zone 22; Class I, Zone 1 and Zone 2; Class I, Division 1, Groups B, C, D.
• Explosion Protection Ratings: CU-TR(applied for): 1 Ex db eb mb ib IIC T6…T1 Gb; Ex tb IIIC T85℃…T450℃ Db
• Conformity to standards: ГОСТ 31610-0, ГОСТ 31610-7, ГОСТ 31610-11, ГОСТ IEC 60079-1, ГОСТ IEC 60079-31, ГОСТ IEC 60079-18ial
• Degree of Protection: IP66
• Internal&external earthing: M6/M8
• Ambient Temperature: -60℃~+60℃
• Internal & External Earthing: M6/M8
• Mounting: Surface type
• HS Code: 853690.
• Country of Origin: China.

Applicable Industries

Explosion-proof Insulated Enclosure are specifically engineered for a wide range of industries and hazardous environments, including petrochemical, natural gas, coal, metallurgy, military, nuclear power, aerospace, firefighting, pharmaceuticals, textiles, grain & oil, municipal services, public security, shipping, ports, railways and so on. Engineered with a robust explosion-proof structure, it delivers long-lasting, corrosion-resistant performance and reliable operation in harsh conditions including high temperatures, heavy dust, and corrosive gases.
It’s a critical link within modern industrial safety frameworks.It is not only a basic enclosure, but also an engineered safety system. Explosion-proof terminal boxes via physical isolation and energy control, delivers paramount security for electrical connections in explosion-prone environments, thereby proving indispensable for the protection of life and property.

Credibility

Warom Explosion-proof Insulated Enclosure are engineered for safety in hazardous environments. With a T6…T1 temperature rating and IP66 protection, they deliver reliable performance. Warom Hazardous Area Insulated Enclosure support your projects with a seamless, end-to-end service — from initial design assessment to final certification, insuring adherence to worldwide occupational health and safety standards.

FAQ

Q1: What is an Explosion-proof Insulated Enclosure?
A1: An Explosion-proof Insulated Enclosure is a specialized protective enclosure designed for hazardous areas. It integrates explosion-proof performance, electrical insulation, and thermal insulation in one structure to ensure safe and stable operation of internal electrical and instrumentation equipment.
Q2: What are the main functions of the Explosion-proof Insulated Enclosure?
A2: The Explosion-proof Insulated Enclosure mainly provides:
Explosion-proof protection to contain sparks and prevent external ignition
Electrical insulation to avoid leakage and static hazards
Thermal insulation to stabilize internal temperature and reduce condensation
High-level dustproof and waterproof protection for harsh environments
Q3: In which industries is the Explosion-proof Insulated Enclosure applicable?
A3: The Explosion-proof Insulated Enclosure is widely used in petroleum, chemical, natural gas, pharmaceutical, mining, grain processing, and other flammable and explosive hazardous locations.
Q4: What advantages does the Explosion-proof Insulated Enclosure have?
A4: The Explosion-proof Insulated Enclosure offers high safety, stable temperature control, strong anti-corrosion performance, high protection rating, easy installation, and low maintenance. It ensures long-term reliable operation in extreme working conditions.
