BT35 Series Explosion-proof Axial...
- ◆The explosion-proof axial flow fan is composed of an explosion-proof motor, blades, and a wind duct among other components.
- ◆ The housing material can be either steel plate or fiberglass reinforced plastic.
- ◆ Quiet Operation: The explosion-proof axial flow fan equipped with vibration-reducing components, it operates with minimal noise.
- ◆ Ideal for Specialized Applications: These ventilation van for hazardous areas erfectly suited for air exhaust and intake in environments like equipment rooms and explosionproof cabins.
TECHNICAL DATA
Explosion Protection Type
Standards: CENELEC, IEC
Zones:
Zone 1 and Zone 2
Product Parameters
Explosion protection:
IECEX((applied for)): Ex db IIC T4 Gb
ATEX(applied for): II 2 G Ex db IIC T4 Gb
Enclosure Material: Steel Plate or Fiberglass Reinforced Plastic
Rated voltage: BT35-11-2.8~BT35-11-5: 220V/380V; BT35-11-5.6~BT35-11-7.1: 380V
Spindle speed: 1450r/min
Inlet thread:G3/4″
Cable outer diameter: Φ10mm~Φ14mm
HS code: 841459
Country of origin: China
Industry & Application
The explosion-proof axial fans is a flameproof type “d” industrial ventilation device designed for hazardous areas containing explosive gases or dust (e.g., Zone 1, 2). As a flameproof axial fan, it provides forced ventilation to mitigate explosion risks, ensuring personnel and equipment safety. These explosion proof axial fans built with corrosion-resistant materials and a rugged design, it delivers reliable performance in the toughest environments—from offshore platforms and chemical plants to ports and grain silos. It is widely applied in environments requiring ventilation where flammable and explosive hazards are present, such as oil and gas extraction, petroleum refining, chemical processing, offshore oil platforms, cruise ships, and military applications.
Credibility
In hazardous locations, using certified explosion-proof equipment isn’t just a recommendation—it’s the law. Choosing compliant explosion-proof axial fans is critical for regulatory compliance and forms the very foundation of safe, legal, and sustainable operations. Our explosion-proof axial fans are engineered and built to the highest global safety benchmarks, holding key international certificates including ATEX, IECEx, and EAC from accredited authorities. They offer you the ultimate advantage of “certify once, deploy globally,” simplifying and securing your international projects.
CTA
For more detailed information on our explosion-proof axial fans customized solutions, or to request a quote, please do not hesitate to contact us. We are committed to providing you with professional solutions and comprehensive technical service support.
FAQ
Q1: What is the fundamental difference between an explosion-proof axial fans and a standard industrial exhaust fan?
A1:Standard fans are not certified for safety in hazardous locations and pose a serious risk. Certified explosion-proof fans are legally required. Their certified “flameproof” enclosure is engineered to contain any internal ignition, ensuring it never triggers an external disaster.
Q2: Are explosion-proof axial fans also suitable for non-hazardous areas?
A2: Yes, but their primary value in such areas lies in their superior durability and reliability. Features like a high Ingress Protection (IP) rating, corrosion-resistant materials, and industrial-grade robust construction can significantly reduce failure rates and extend service life. However, its cost-effectiveness needs to be taken into consideration.
Q3: How to choose the corresponding explosion-proof axial fans when in an environment where flammable gases and corrosive media (such as chemical workshops) coexist?
A3: Match TWO criteria: Explosion Protection: Correct Gas Group & Temperature Class; Corrosion Resistance: Specify special materials (e.g., Stainless Steel).
Q4: Can explosion-proof axial fans be used in food or pharmaceutical industries (non-hazardous areas) requiring frequent washdowns? What are the advantages?
A4: Absolutely! They are the superior choice for hygiene-critical washdown areas. Superior sealing (high IP) withstands pressure washing, and Stainless steel meets sanitary standards.
